FBT ARCHON 215S
Bass reflex Compact Passive Subwoofer - 2x15" - 2000Wrms -
Artnr. 703842
The Archon 215S is ideal for the discerning client or integrator who requires substantial bass reinforcement.Featuring twin 15″ Drivers with 4″ voice coils This subwoofer delivers outstanding performance.
- Stylish architectural cabinet design
- Acoustically transparent steel grilles with protection cloth
- High SPL, fast responding dynamics, excellent intelligibility, wide band, extremely low distortion
- Baltic birch plywood cabinets available in black or white extra texture paint
- Choice of different RAL paint colours on order
- Choice of different paint finish: glossy, matt, textured and more, on order
- Custom designed low frequency woofers, made in Italy
- Custom designed high frequency compression drivers, made in Italy
- Rotatable horns for optimal horizontal or vertical sound dispersion angle
- Selectable bi-amp/full range crossover network
- Full suspension possibilities through multiple M10 / M5 threaded rigging points and a wide range of mounting hardware
- Possibility to install line transformers for 100V/70V applications
- Possibility to order weatherproof versions for outdoor use
- Possibility to extend low frequencies performance through dedicated and compact subwoofers (Archon 208S, Archon 215S)
INPUT CONNECTOR:
2 x speakon NL4 in & thru
DIMENSION (WXHXD):
900 x 485 x 640 mm
WEIGHT:
50 kg
FREQUENCY RESPONSE:
35Hz - 500Hz -6dB
LOW FREQUENCY WOOFER:
2 x 15 - 3 coil inch
MAXIMUM SPL CONT/PEAK:
139/142 half-space dB
DISPERSION:
omni HxV
CROSSOVER FREQUENCY:
external active KHz
RECOMMENDED AMPLIFIER:
2000 W RMS
LONG TERM POWER:
1000 W
SHORT TERM POWER:
4000 W
NOMINAL IMPEDANCE:
4 ohm
CONFIGURATION:
1 way
