FBT MITUS 206L
Passive Line Array - 2x6,5" + 1,4" - 500Wrms+150Wrms
Artnr. 703726
The FBT MITUS 206L is a two-way compact line line array system featuring 2 x 6.5” B&C neodymium woofers with 1.7” voice coil and 1.4” exit B&C neodymium driver with 2.5” voice coil. All in a Polypropylene gas-injected enclosure. 500W + 150W – 16ohm 129dB SPL LF / 133dB SPL HF
- Compact 2-way, bass-reflex design
- Passive version, recommended amplifier of 500Wrms / 16ohm LF and 150 Wrms / 16ohm HF
- Internal HF protection
- Neutrik Speakon NL- 4MDV connectors IN & LINK OUT
- External digital processor requie
- 2 x 6.5’’ (165 mm) B&C neodymium woofers with 1.7’’ (44 mm) coil
- 1.4’’ (36 mm) exit B&C neodymium driver with 2.5’’ (64 mm) coil
- Frequency response from 75Hz to 20KHz
- 100° horizontal waveguide with very low distortion and near flat wavefront up to 18Khz
- High impact polypropylene gas-injected enclosure with integrated rigging hardware adjustable with 0° to 10° angle between cabinets at 2° step
- Ideal for small to medium sized application, from single pole mounted loudspeakers with 100°H x 10°V coverage to multiple cabinet full sized line array, the MITUS 206L maybe used also in outdoor applications where the system is not directly exposed to the elements
- Wide range of hardware accessories for flying and ground stacked configurations
- Very lightweight, only 13.5Kg
INPUT CONNECTOR:
2 x speakon NL4MD-V in & thru
DIMENSION (WXHXD):
574 x 220 x 383 mm
WEIGHT:
13.5 kg
FREQUENCY RESPONSE:
75Hz - 20Khz -6dB
LOW FREQUENCY WOOFER:
2x6.5 - 7.1coil neodumium inch
HIGH FREQUENCY DRIVER:
1x1.4 - 2.5 coil neodymium inch
MAXIMUM SPL CONT/PEAK:
125/129LF - 129/133HF dB
DISPERSION:
100°x10° max dependant upon n° of element HxV
RECOMMENDED AMPLIFIER:
500LF/150HF W RMS
LONG TERM POWER:
250LF/70HF W
SHORT TERM POWER:
1000LF/300HF W
NOMINAL IMPEDANCE:
16LF/16HF ohm
CONFIGURATION:
2 way
