FBT X-SUB 18SA

Processed Compact Band-pass Active Subwoofer - 18" - 1200W

Artnr. 703535

Flera modeller tillgängliga

Beskrivning

Compact band-pass design subwoofer with high SPL and punch.
460mm (18”) high excursion woofer with 75 mm (3”) voice coil.
Frequency response from 38Hz to 120Hz.
1200W Class D power amplifier with switch mode supply.
Digital Signal processor with 6 presets, 2 equalization with 2 LPF crossover settings.
Control panel with stereo combo XLR/Jack in/outs, Stereo XLR HP-Filter outs, Volume, EQ presets, phase reversal switch 0°-180°, status LED indicators.
18mm plywood cabinet with scratch & scuff resistant paint finish.
M20 (20mm) top mount speaker stand socket, two FBT design aluminum handles, 100mm optional wheels.
Provides additional low frequency reinforcement when used along with X-PRO or X-LITE speaker series.

DIMENSION (WXHXD):
510 x 692 x 650 mm
WEIGHT:
34 kg
INPUT CONNECTOR:
XLR ST with loop, XLR ST OUT
POWER CORD:
5 / 16.4 m/ft
MAXIMUM SPL CONT/PEAK:
136 half- space dB
DISPERSION:
omni HxV
INPUT IMPEDANCE:
22 Kohm
BUILT-IN AMPLIFIER LF/HF:
1200 W RMS
FREQUENCY RESPONSE:
38Hz - 120Hz -6dB
LOW FREQUENCY WOOFER:
18 - 3 coil inch
CONFIGURATION:
1 way

Artnr. 703547

FBT XS-C 18S

Cover for X-SUB 18SA

Artnr. 703548

FBT XS-CH 18S

Cover for X-SUB 18SA with wheels
