• Ljudsystem

Yamaha MTX3

Matrix Processor

Artnr. 802740

  • Inputs; 8 mono (mic/line), 2 stereo (line), 16digital (via YDIF*)
  • Outputs; 8 mono (line), 16 digital (via YDIF*)
  • Can expand YDIF* equipped inputs and outputs with Exi8/Exo8 expanders
  • SD Card Slot for playback of MP3/WAV files stored on an SD Memory Card
  • Functions for worry-free operation; Feedback Suppressor, Auto Gain Control, Priority Ducker and Dugan Automixer
  • Two useful digital processors “Reverb” and “Echo” for entertainment applications
  • Remotely control the volume and presets of multiple zones with DCP series wall mount digital controllers
  • Wireless DCP for iPhone and iPod touch is free available on the App Store
  • Equipped with Network port and GPI ports that offer compatibility with touch panel controllers such as AMX/Crestron
  • Easy setup and parameter control with MTX Editor


* YDIF: the newly developed digital transmission format; a unique propriety Yamaha technology that delivers 16ch audio and word clock transmission via standard CAT5 Ether cable

480 x 44 x 362 mm
4,8 kg
Yamaha DCP1

Artnr. 802742

Yamaha DCP1V4SEU 1vol/4switch

Digital kontrollpanel för MTX/MRX

Yamaha DCP4V4S-EU

Artnr. 802743

Yamaha DCP4V4SEU 4vol/4switch

Digital kontrollpanel för MTX/MRX

Yamaha MCP1

Artnr. 802744

Yamaha MCP1

Väggmonterad kontrollpanel för MTX/MRX

Yamaha DCH8

Artnr. 802736

Yamaha DCH8

Digital Controller Hub för DCP -paneler.
