FBT VENTIS 115MA

2-way Bass reflex Active monitor - 15" + 1" - 700Wrms+200Wrms

Artnr. 703505

Flera modeller tillgängliga

The FBT VENTIS 115MAbi-amplified speaker feature 0,59″ birch plywood costruction covered in a scratch & scuff resistant black finish. The FBT VENTIS 115MAis a two way design incorporating a 15″ coaxial custom woofer with 2,5″ voice coil and 1″ exit throat B&C with 1,7″ voice coil. With a frequency range of 50Hz – 20kHz provides hi fedelity sound for both speech and music applications with a maximum SPL of 132dB. The biamplified FBT VENTIS 115MA features 700W RMS low frequency amp and 200W RMS high frequency amp. DSP on board is both user friendly and powerful; a total of 6 pre-optimised settings are available, plus 2 further slots for users to form their own design, using 5 parametric equalizers per slot. Control panel features balanced XLR/Jack input, XLR link out, 2 x volume, RCAstereo input, DSP display with rotative encoder and push, The optional mounting bracket allow the FBTVENTIS 115MAspeaker to be surface mounted on wall or ceilings. Thanks to the integrated steel pole mount, the FBTVENTIS 115MAcan be turned into a standard speaker in vertical configuration with a few simple moves.

  • 2-way bi-amplified bass-reflex design
  • 15″ coaxial custom woofer
  • 1″ exit throat B&C
  • 700W + 200W RMS buil-in Class D power amplifier
  • 90° conical dispersion
  • DSP with 6 factory presets
  • 0,59″ birch plywood enclosure
  • Wall bracket mount thread (optional)
  • 1,38″ top-hat
  • Two integrated handles
CONFIGURATION:
2 way
AC POWER REQUIREMENTS:
640 VA
MAXIMUM SPL CONT/PEAK:
127/133 dB
DISPERSION:
90° HxV
INPUT IMPEDANCE:
22 Kohm
BUILT-IN AMPLIFIER LF/HF:
700/200 W RMS
BUILT-IN AMPLIFIER PEAK LF/HF:
1400/400 W
FREQUENCY RESPONSE:
50Hz - 20KHz -6dB
HIGH FREQUENCY DRIVER:
1 - 1.7 coil inch
LOW FREQUENCY WOOFER:
15 - 2.5 coil inch
DIMENSION (WXHXD):
632 x 354 x 516 mm
WEIGHT:
21.3 kg
